Hydraulic swing beam shearing machine

Price: 7285.35 USD
Payment Terms: T/T,L/C
Place of Origin: Anhui, China (Mainland)
inquire
Add to My Favorites
HiSupplier Escrow
Share |

Product Detail

Model No.: QC12K-4X3200
Production Capacity: 3000
Delivery Date: 25
Raw Material: Steel Bar
Extra Services: Cut To Length
Certification: CE
Brand Name: ZYMT
Main motor: Siemens Germany
Electrics: Schneider France
Hydraulic valve: Rexroth Germany
Pipe connector: EMB Germany
Backgauge travel: 600MM
Means of Transport: Ocean,Land,Air
Packing: plastic cover
Power: Hydraulic
Machine Type: Others
Automation: Automatic
Material / Metal Processed: Stainless Steel
Product Name: Hydraulic swing beam sheari...
Backgauge motor: Estun Nanjing China
Seal ring: Nok Japan
Pump: Sunny USA
Footswitch: Karcon South Korea

Hydraulic swing beam shearing machine

all types of NC/CNC hydraulic shearing machine

The machine is metal plate welded structure, with hydraulic transmission and accumulator return, typical of an easy operation, reliable performance, and nice appearance, fitted with digital controller.
Indication by indicator is provided for adjustment of blades clearance, for a handy and prompt adjustment.
Alignment device with lighting and control device for shearing stroke are set.
Worktable with balls for material feeding convenient, to minimize fish tail with sheet bar and to reduce frictional resistance.

 Equipment for QC12Y&QC12K

                          China Taifeng Hydraulics
                          German BOSCH Hydraulics
                          Oil Pump
                          Pipe Connectors
                          China Gear Pump
                          BOSCH Pump
                          Manual Blades gap Adjust Wheel
                          Angle Measure
                          Electrics
                          Light Guards
                          Ball Screw Linear Guide
                         Back gauge Pneumatic Support



Controller System
DAC310
Bright LCD 128×64 display
Backguage control, Gap control, Stroke length limitation.
Actual and programmed position visualization, Stock counter,
Programmable up to 100 steps.
Panel-based housing;
Servo control/unipolar/AC two-speed control;
mm/inch transmission;
E200S
Backguage control, bus mode control servo system;
Stroke length limitation, double pragrammable digital output;
Pragram memory of up to 40 program, up to 25 steps per program;
One side positioning, retract of function.
mm/inch transmission, Chinese/English transmission;
240×128 pixels LCD display.
 E21S
Backguage control, control for general AC motor, frequency inverter;
Intelligent positioning, double programmable digital output;
Stock counter, program memory of up to 40 programs, up to 25 steps per program;
One side positioning, retract of function.
One key backup, restore of parameters;
mm/inch transmission, Chinese /English Transmission; LCD display.

 P40

Analog or digital outputs for 1-3 speed operation 16 free programmable digital in-/outputs

Program memory(1000 sets)

Angle control/gap control/backguage
Limitation of the cutting length
Material List for angle and gap control

HT071
Regulated power supply for encoder or push pull/o.c.
optional line 12 Vdc±5% 120 mA
Optoisolated inputs
High luminosity led display having 6 digits plus sign for position,
2 digits fpr cycles and for programs.
Possibility to save up to 99 programs composed of 20 cycles.
Each cycle can count 65000 repetitions at maximum
Data and programs are saved in a flash memory without floating battery Ip 65, polycarbonate, water and abrasion-proof keyboard with tactile sensitivity.

China ESTUN E10S
X axis and Y axis position display;
Resolution:0.1mm or 0.0001 inch;
Stock counter, 2 timer integrated;
One side positioning indication;
Sofware limitation;Power-off memorization.QC12Y-6x2500 hydraulic swing beam nc shearing machine with good price QC12Y-6x2500 hydraulic swing beam nc shearing machine with good price QC12Y-6x2500 hydraulic swing beam nc shearing machine with good price QC12Y-6x2500 hydraulic swing beam nc shearing machine with good price QC12Y-6x2500 hydraulic swing beam nc shearing machine with good price
